uuustore 7 Inch HD FPV Monitor - High Quality LCD5802S LS5802S 5802D 40CH Raceband 5.8G 7 Inch Diversity Receiver HD Monitor with Build-in Battery for FPV Drone

High Quality uuustore LCD5802S LS5802S 5802 40CH Raceband 5.8G 7 Inch Diversity Receiver HD Monitor with Build-in Battery

Remark:

LCD5802S  is without dvr

LCD5802D is with DVR

Description:
Brand Name: uuustore

Item Name: LCD5802S Monitor
Built-in 5.8Ghz Dual diversity receiver automatically for best reception
Built-in 2CH 5.8Ghz AV output and 1CH AV input
Built-in high performance Li-POLYMER Battery: 2000mAH/7.4V
Work status OSD display : RSSI indication ; Battery indicator;Channel indication
A key to automatic signal search
Support Chinese and English menu
Screen size:7”
Screen type:TFT LCD Screen/long life, LED backlight
Resolution: 800*480
Brightness: 600cd/m2
View Angle:140/120degree (Horizontal/Vertical)
Size:180mm x 120mm x 50mm(Note:Sunshield height:28mm)
Working Voltage: DC 7~16V
Power Consumption: max 650 mA @12V
Battery charging current : 850mA @12V ( max )
Working temperature: -10~+ 65
Connectors:RP-SMA female(outer needle)
Antennas Connectors:RP-SMA male (inner hole)


Features:
Built-in Dual Receiver Automatically for best reception Automatic Antenna Switching
Dual buffered AV outputs
Not affect by 2.4GHz R/C Radios
AV Receiver with Diversity inputs
Small, light weight, durable
5 bandss and total 40 Channels
Built-in battery , easy to carry and outdoor use
A key to automatic signal search,Simple operation
Work status OSD display:Always be aware of the device working condition.
Notice: It can\'t receive 2 different channels at the same time

bands and Channel selection
