Zingto INYYO Q303 Drone Camera Gimbal - 1080P EO 640 IR Thermal 2K LRF Triple Sensors Pod

Zingto INYYO Q303 Drone Camera Gimbal - 1080P EO 640 IR Thermal 2K LRF Triple Sensors Pod

Zingto

$11,699.00 USD
$11,699.00 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.

3 orders in last 90 days
  • PayPal
  • Visa
  • Mastercard
  • American Express

Warehouse: China/USA/Europe, can delivery to all countries;

Free Shipping: 9-15 days;

Express Shipping: 5-8 days;

Return&Refund: 30 Days.

View full details

Zingto INYYO Q303 Specifications

Parameter Value
Material Aviation / Aircraft aluminum alloy
Pod Size (L × W × H) 138.1 × 130 × 208 mm (Typical)
Pod Weight Approx. 1189 ± 10 g
Gimbal Stabilization Three-axis mechanical stabilization
Compensation frequency up to 1250 Hz
Control Angle Range 360° × N (Yaw),
–120° ~ +30° (Pitch),
±40° (Roll)
Operating Temperature –20 °C ~ +60 °C
Storage Temperature –30 °C ~ +70 °C
Ingress Protection IP43
Visible Focal Length Range 4.8 – 158 mm (up to 33× or similar optical zoom)
Visible Light Resolution 1920 × 1080
Optical Dynamic Range (Visible) Up to 120 dB (starlight telephoto camera)
Minimum Illumination (Color) 0.001 Lux (ultra low)
Focus Speed <1 s (extreme speed and precision)
ICR Filter Automatic day/night switching
Thermal Imaging Resolution 640 × 512 (common spec in images)
Some images mention 1280 × 1024 as another variant
Thermal Imaging Focal Length 25 mm (uncooled infrared lens variant)
Thermal Sensitivity ≤50 mK @ 25 °C
Pixel Pitch (Thermal) 12 µm
Thermal Frame Rate Up to 50 Hz
Laser Ranging Range 5 – 2000 m (often extended up to 6000 m in some variants)
Ranging Accuracy ≤ 1 m (some variants: ±2 m)
Laser Wavelength 905 nm (some variants: 1535 ± 10 nm)
Optical Zoom Coaxiality Within 1% error; ~99% coaxial alignment
Recognition Distances (Visible) Manual: Soldier ~2500 m, Vehicle ~3000 m
AI: Soldier ~1500 m, Vehicle ~2000 m
Recognition Distances (Thermal) Manual: Soldier ~600 m, Vehicle ~1500 m
AI: Soldier ~400 m, Vehicle ~1000 m
Control Mode Speed control; Angle control
Control Signal S.BUS, TTL UART, TCP, UDP
Video Output 1920 × 1080 @ 30 fps
Video Storage MP4
Photo Storage JPG
AI Chip 22 nm quad-core 2.0 GHz,
built-in NPU (~1.0 Tops for Q303 variant;
up to 6.0 Tops for Q350+ variants)
Detection & Recognition Accuracy Multiple targets simultaneously
Detection probability >85% (some variants >95%)
Recognition probability >80% (some variants >90%)
False alarm <15% (some variants <10%)



Zingto INYYO Q303 Details

Capture life breathtaking moments with Zingto INYYO Q303 drone camera gimbal, ideal for travel and exploration.

Capture life most breathtaking moments with Zingto INYYO Q303 Drone Camera Gimbal, perfect for travel and exploration.

The Zingto INYYO Q303 Drone Camera Gimbal features thermal imaging, adjustable angles, and supports various signal protocols.

The Zingto INYYO Q303 Drone Camera Gimbal features a thermal imaging resolution of 640*512, with control angles ranging from -120 to 30 degrees and a roll angle of 1402. It has speed and angle controls, supporting S.BUS, TTL UART, TCP, and UDP signals. Video output is 1920*1080 at 30fps.

The Zingto INYYO Q303 Drone Camera Gimbal features advanced stability with triaxial stabilization and intelligent focusing with a Sony camera.

The Zingto INYYO Q303 Drone Camera Gimbal features advanced stability with a triaxial stabilization system and high-speed processor. It also has intelligent focusing with a Sony 33x optical zoom camera, capable of 360-degree rotation and up to 180mm focal length. The gimbal supports ICR infrared filter and thermal imaging.

Zingto INYYO Q303 Drone Camera Gimbal, The INYYO Q303 drone camera gimbal features a highly sensitive infrared detector with stable chemical properties and high thermal conductivity.

The INYYO Q303 drone camera gimbal features a highly sensitive infrared detector with ceramic package, ensuring stable chemical properties and high thermal conductivity. The module fuses thermal imaging with visible light images for detailed monitoring. It also includes efficient infrared temperature measurement technology and accurate laser ranging capabilities.

The ZINGTO INYYO Q303 drone camera gimbal features a quad-core chip with NPU computing power for target detection and recognition.

The ZINGTO INYYO Q303 drone camera gimbal features a quad-core chip with NPU computing power, enabling automatic detection and recognition of targets like vehicles and personnel. It has high-precision tracking, real-time data transmission, and quick detachable full metal heat dissipation for reliable performance.

The Zingto INYYO Q303 drone camera gimbal offers unrestricted use with various platforms and peripherals.

The Zingto INYYO Q303 drone camera gimbal features compatibility with various mechanical platforms and peripherals, offering unrestricted use. It has a multi-rotor/helicopter robot yacht fixed/compound wing design, plus features like shock absorption, low wind resistance, and open control protocol for PC and Android software clients.

Zingto INYYO Q303 Drone Camera Gimbal, Drone camera gimbal captures high-quality image with ease.

Drone camera gimbal captures high-quality image with ease.
