Axisflying 640 Thermal Imaging Camera - 640*512 60FPS 40MK Thermal Camera for FPV Drone Camera

Axisflying 640 Thermal Imaging Camera - 640*512 60FPS 40MK Thermal Camera for FPV Drone Camera

Axisflying

$381.07 USD
$457.29 USD $381.07 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

16 orders in last 90 days

Color
  • PayPal
  • Visa
  • Mastercard
  • American Express

Warehouse: China/USA/Europe, can delivery to all countries;

Free Shipping: 9-15 days;

Express Shipping: 5-8 days;

Return&Refund: 30 Days.

View full details

Axisflying 640 Thermal Imaging Camera Specs

Feature Specification
Model GE-3F
Resolution 640x512
Detector type Vanadium Oxide Uncooled Infrared Focal Plane Detector
Frame rate 60fps
Pixel spacing 12um
NETD 40mk
Response band 8~14um
Lens spec 9.1mm F1.0 / 13.5mm F1.0 / 18mm F1.1
FOV (H*V) 9.1mm: 48.7°x38.6°, 13.5mm: 31.9°x25.7°, 18mm: 24.2°x19.5°
Whether to image Yes
False color type White hot
Input Voltage 4.5-18V
Output type CVBS
Analog Video PAL
Module volume (excluding lens) 21*21
Weight (without lens) <8g
Operating temp -40°C~+80°C
Storage temp -50°C~+85°C
Brand AXISFLYING




Descriptions

  • High-Resolution Imaging: 640x512 pixel Vanadium Oxide Uncooled Infrared Detector ensures detailed and sharp thermal images.
  • Lightweight Design: Weighs less than 8 grams (without lens), making it highly portable and ideal for applications where every gram counts.
  • Easy Integration: Compact module dimensions of 21*21 for straightforward incorporation into a variety of systems.
  • Energy-Efficient: Operates on a low input voltage range of 4.5-18V for eco-friendly and prolonged use.
  • Adaptive Lens Options: Multiple lens specifications (9.1mm, 13.5mm, 18mm) to suit different field of view requirements.
  • Smooth Frame Rate: Captures fluid motion at 60 frames per second, crucial for both live monitoring and detailed analysis.
  • Enhanced Sensitivity: Features a NETD of 40mk, capturing subtle temperature differences effectively.
  • White Hot Imaging: The false color 'white hot' mode enables easy interpretation of heat signatures.
  • Durable: Operates reliably within a temperature range of -40°C to +80°C and stores safely between -50°C to +85°C.
