DUSTPROOF AND WATERPROOF

The frame is dustproof and waterproof, and the waterproof level reaches IP65 and can be washed directly with water

CROSS-FOLDING STRUCTURE

The arm adopts cross-folding and staggered folding method, which minimizes the folded size and facilitates transfer and transportation

20L LARGE CAPACITY

20L large medicine tank capacity, larger spraying area

ONE MACHINE FOR MULTIPLE USES (SPRAY + SPREAD)

The spreading system and spraying system can be quickly replaced to meet the operation requirements of two different scenarios Spraying system installation effect Spreading system installation effect

Versatile Multi-Application Drone - Quickly Switch between Spreading and Spraying Functions

Dimensions: Mainframe - 6 Axis Agriculture Drone (Package Size: 620 x 360 x 295 mm) by EFT Electronic Technology Co., Ltd.



EFT's latest 2021 GX series drone for agriculture has released, the GX series aircraft is based on the same body and there are 4 types of the models: G420, G620,G626 and G630.

Item Model	G420	G620	G626	G630
Axis	4 Axis	6 Axis	6 Axis	6 Axis
Tank Capacity	20L	20L	26L	30L
Wheelbase	2028mm	2028mm	2028mm	2028mm
Suggest Powe Combo	Hobbywing X9 Plus+36" Propeller	Hobbywing X9+34" Propeller	Hobbywing X9 Plus+36" Propeller	Hobbywing X9 Plus+36" Propeller

EFT G620 is one 20L high capacity platform specially designed for agriculture applications. The effective capacity of the drone is 20L. The drone adopts a quick-release water tank and battery, compact body, light in weight and convenient to fold. The frame kit or the Frame with the power combo is compatible with the mainstream flight controllers in the market, such as the JIYI K++, JIYI K3A Pro, Topgun, Hex Cube, PIX flight controller and etc.

Specifications:
Item Brand: EFT
Item Model: GX620
Wheelbase: 2028mm
Size (Unfolded): 2642 x 2569 x 885mm
Size (Folded): 1192 x 623 x 885mm
Tank Capacty: 20L
Frame Weight: 10.85kg
Frame+Power System Weight: 20.45kg
Frame+Power+Spraying system weight: 22.45kg
Non-Load take-off Weight: 31.2kg
Full take-off Weight: 51.2kg

Flying time test:
Non-Load Flying Time: 20 minutes 32 seconds  (48V)
Full-load Flying Time: 8 minutes (47V)

Note: During the test, we use the Tattu 14S 22000mah battery, hobbywing X9 power combo.

Main Features:
Integral Frame
The frame is integrally formed, with a simplified structure, strong strength, and good durability and reliability.

Crossfolding Method
The arms of the G616 are folded in a staggered way, minisize the folding size, more convenient for transportation.

Dustproof and Waterproof
The whole drone is dustproof and waterproof, and the waterproof grade reachs IP65. The frame can be washed directly with water.

Two battery solutions
There are two power plugs reserved for the drone. One is with the QS9L plug for the normal smart battery. And the other is specially designed for Tattu V3.0 Quick-remove batteries.

There are two types of power connectors, AS150U and MOLEX. The AS150U connector is a single connection type for the regular Tattu 12S 16000mah and 12S 22000mah (AS150U).
The MOLEX type is for TATTU 3.0 22000mAh (MOLEX) connections, which is a bit more expensive as it comes with an anti-spark module for MOLEX batteries and an OLEX connector.

Multiple Uses (Spraying + Spreading)
The spreading system and spraying system can be quickly replaced to meet the operation requirements of the two different scenarios.

Package Contents: G620 Frame, Includes Three Boxes: Box 1: Mainframe (760 mm x 574 mm x 313 mm) Box 2: OS (795 mm x 125 mm x 1 mm) (Note: Assuming





EFT G620 20L Agriculture Drone - High-Quality Product with Excellent Service and Fast Shipping to Chile, backed by Tantastc's reliable supplier network. John Clinton (Unamed) - Very Satisfied Customer: 'Satisfacción garantizada' (Guaranteed Satisfaction)

EFT COOPERATORS

With the spirit of craftsman, providing high performance drone frames and seeding and spraying systems to support commercial uavs development worldwide is the purpose of EFT development.
Has won the trust and praise of major brands in more than 100 countries around the world.

EFT Electronic Technology Co., Ltd. is a leading provider of innovative UAV solutions, boasting a robust Research and Development (R&D) team and a portfolio of dozens of core patents. Our product range includes agricultural drone frames, granule spreaders, power modules, and more.

EFT G620 Agriculture Drone meets international quality standards, certified by CE (Conformité Européene) and FCC (Federal Communications Commission), ensuring safe and reliable operation.
