X08 V5.0 Specifications

The product features a voltage range of 3.8-8.4V, with a stall torque of 2.7 kg-cm at 7.4V and an angle range of -60° to +60°. The servo has the following specifications: case material is aluminum alloy, unload speed is 500°/sec, motor type is coreless metal gear, rated speed is 380°/sec, sensor type is potentiometer with a travel of 1609, and angle feedback option available. It can operate within a temperature range of -10°C to +55°C and has a wire type of 28AWG. Storage temperature should be within the same range.

Product Specifications: KST X08 V5.0 Metal Gear Servo - Coreless Motor Version * Voltage Range: DC 3.8-8.4V * Torque: 2.7kg.cm @ 7.4V (Stall Current: 9g) * Rated Torque: 0.15A (at 3802/second) and 0.24A (at 3756/second) * Rated Speed: Up to 500
