T-motor ALPHA 120A HV ESC - Electronic Speed Control For Multi-rotor Quadcopter UAV RC Drones smart control and data feedback

T-motor ALPHA 120A HV ESC - Electronic Speed Control For Multi-rotor Quadcopter UAV RC Drones smart control and data feedback

T-Motor

$196.83 USD
$236.20 USD $196.83 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

14 orders in last 90 days

Default Title
  • PayPal
  • Visa
  • Mastercard
  • American Express

Warehouse: China/USA/Europe, can delivery to all countries;

Free Shipping: 9-15 days;

Express Shipping: 5-8 days;

Return&Refund: 30 Days.

View full details

T-motor ALPHA 120A HV ESC SPECIFICATIONS

Brand Name: T-MOTOR

Origin: Mainland China

Material: Metal

Recommend Age: 14+y

RC Parts & Accs: Motor Components

Size: 110*55*25mm

For Vehicle Type: Airplanes

Use: Vehicles & Remote Control Toys

Model Number: ALPHA-120A-HV

matchable motor: U12 II KV120/ U13II KV130

T-motor ALPHA 120A HV ESC SPECIFICATIONS BrandT-motor ALPHA 120A HV ESC, Basic Parameter Size 110*55*25mm (L'W'H) Weight (

Basic Parameter Size 110*55*25mm (L'W'H) Weight (Incl cables) 3PCS Power Cable Silicone wire-deep orange-12AWG-75MM Signal Cable PVC flat cable 30 core wires-2-4OOMM (white_ blank: black/ JP 3P male connector)

T-motor ALPHA 120A HV ESC, IOOA Throttle Pos. Range 100-1940us Peak Current (1Os)

The IOOA Throttle has a position range of 100-1900μs (microseconds), a peak current rating of 120A, a throttle refresh frequency of 500Hz, and a standby consumption of 50mA.

T-motor ALPHA 120A HV ESC, ALPHA FOC TECHNOLOGY A revolutionary ESC based on FOC

Featuring ALPHA FOC Technology, this revolutionary Electronic Speed Control (ESC) employs Sine Wave Field-Oriented Control (FOC) and intelligent algorithms to deliver efficient, accurate, and stable motor control, ideal for professional applications.

T-motor ALPHA 120A HV ESC, the principle of "field-oriented control" is to control motor output via the adjustment of current

The principal concept of 'field-oriented control' involves regulating motor performance by adjusting current flow and angle, thereby ensuring efficient operation with low noise, minimal temperature increase, high responsiveness, linear throttle control, and energy recycling capabilities.

T-motor ALPHA 120A HV ESC, ALPHA ESCs are more efficient with excellent performance for long flight time .

Alpha ESCs demonstrate superior efficiency, enabling longer flight times. Compared to traditional square-wave driving methods, they provide faster response times, reduced pulse currents, and a smoother startup experience.

T-motor ALPHA 120A HV ESC, multiple protections enables ALPHA ESC to timely detect parameters as to voltage, current

Featuring intelligent multiple protection designs, the ALPHA ESC continuously monitors key parameters such as voltage, current, and temperature. In the event of any abnormalities, it adjusts and compensates to ensure optimal performance and extend the lifespan.

T-motor ALPHA 120A HV ESC, Nano coating technology is adopted in ALPHA ESC PCB A IPSS keep water and

The ALPHA 120A HV ESC features a lightweight design that incorporates nano-coating technology on its PCB (Printed Circuit Board) to protect it from liquid corrosion, ensuring safe operation in harsh environments. Additionally, this design boasts IP67 rating for waterproof and dust-resistance, as well as enhanced cooling performance.

T-motor ALPHA 120A HV ESC, Efficient Cooling FOC driving without hybrid current reduces ESC temperature . Novel

Equipped with efficient Field-Oriented Control (FOC) technology, our T-Motor ALPHA 120A HV ESC features reduced current hybridization, which minimizes heat generation and ensures optimal cooling performance. Our innovative design contributes to a significant temperature drop of over 10%, allowing for smooth and reliable operation.

T-motor ALPHA 120A HV ESC, motor recharges the battery reversely for flight time extension:T-motor ALPHA 120A HV ESC, ESC MOTOR Volt: Prop U3-KV7OO 16V 12CF

Recommended motor and ESC combinations include: U3-KV700 (16V), U3-KV12CF, MN40-06-K V380, MN40-14-K V4000, US-KVP4000.

T-motor ALPHA 120A HV ESC, ALPHA 60A 12S V1.2 MNZOSS-KV125 48V

ALPHA 60A 12S V1.2 MNZOSS-KV125 48V 27CF U8II / U8lite / KV1OO 48V 28CF MN8O1S- KV12O 48V 29CF .
