Overview
The CoreWing F405 WING MINI V2 Flight Controller is a compact control board for fixed-wing, V-tail, flying-wing, VTOL, and FPV airframes. Its stacked 6-layer PCB design combines dedicated peripheral connections, PWM outputs, power regulation, and configurable VTX power management in a compact installation format.
Key Features
- Six-layer PCB with thicker copper construction.
- 9 PWM pin-header outputs plus 3 additional PWM solder-pad outputs.
- Up to 6 UART ports for expansion, including GPS, telemetry, HD or analog VTX, and external ELRS/CRSF receiver connections.
- Dedicated GPS, VTX, receiver, camera, telemetry, and SBUS connection points for organized wiring.
- Dual-sided solder pads allow either board side to face upward for installation flexibility.
- Supports HD and analog VTX connections with selectable VSW output: VBAT or 5V. VSW is set to VBAT by default.
- Switchable VTX power can be assigned to a 2-position transmitter switch to reduce VTX heat during ground setup.
- Compatible with ArduPilot, INAV, and Betaflight firmware through the CoreWing app interface.
- Wireless tuning is supported through the Wireless USB Extender SE, providing BLE and Wi-Fi connectivity, USB-C wired tuning, and expansion ports. Wireless tuning range is up to 30 meters and varies with installation, environment, and mobile device.
Specifications
| Model | F405 WING MINI V2 |
| PCB Layers | 6-layer |
| PWM Outputs | 9 pin headers + 3 solder pads |
| UART Ports | Up to 6 |
| Flight Controller BEC | 5.2V 2A |
| Servo BEC | 5V 4A |
| VTX Compatibility | HD and analog VTX |
| VTX Power Output | VBAT or 5V selectable |
| Supported Airframes | Fixed-wing, V-tail, flying wing, VTOL |
| Firmware Support | ArduPilot, INAV, Betaflight |
Header Options
Available with headers not soldered or with straight headers soldered. For configuration assistance or product support, contact rcdrone.top.
Applications
Suitable for compact fixed-wing RC aircraft, flying wings, V-tail aircraft, VTOL platforms, and FPV builds requiring multiple PWM outputs, UART expansion, GPS, receiver, telemetry, camera, and VTX connections.
Details
The compact stacked design combines organized peripheral connections, configurable VTX power, and wireless setup support.
Dedicated connection points help keep GPS, receiver, camera, VTX, and telemetry wiring orderly in a fixed-wing build.
Dual-sided solder pads allow either side of the board to face upward when installation space or cable routing requires it.
The Wireless USB Extender SE adds BLE and Wi-Fi tuning, USB-C wired access, buzzer connection, and expansion ports.
BLE and Wi-Fi status indicators make it easier to confirm the active wireless connection during app setup.
Firmware updates can be initiated through the CoreWing app without a computer-based setup workflow.
Wireless app tuning supports flexible ground-based configuration, with range varying by installation, environment, and mobile device.
Assigning VTX power to a two-position transmitter switch can reduce video-transmitter heat before flight.
Up to six UART ports support expansion for GPS, telemetry, VTX, receivers, and related peripherals.
Nine PWM pin-header outputs plus three solder-pad outputs support flexible airframe and servo layouts.
Separate sensor and power layers, along with 5.2V flight-controller and 5V servo BECs, support organized power distribution.
HD and analog VTX connections are supported with a selectable VSW output of VBAT or 5V.
An optimized UART layout helps reduce port interference during DFU firmware updates.
The CoreWing F405 Wing Mini V2 uses a compact 26 x 37 mm board layout with an 18 mm overall stack height.
CoreWing F405 WING MINI V2 hardware includes the flight controller, connector boards, pin headers, mounting hardware, and wiring accessories for installation.
The CoreWing F405 WING MINI V2 uses a labeled connector and pinout layout to help streamline wiring during installation.
