  • GEPRC SPEEDX2 1104 7500KV Motor, 1104 7500kv motor with copper windings and black casing.
  • GEPRC SPEEDX2 1104 7500KV Motor, GEPRC SPEEDX2 1104 7500KV motor features N52H magnets and NMB bearings.
1 6

GEPRC SPEEDX2 1104 7500KV Motor - N52H, NMB Bearings, 2-3S LiPo, 155W, 5.2g for FPV Drone

GEPRC SPEEDX2 1104 7500KV Motor - N52H, NMB Bearings, 2-3S LiPo, 155W, 5.2g for FPV Drone

GEPRC

$19.00 USD
$19.00 USD
Promotion Épuisé
Taxes incluses. Frais d'expédition calculés à l'étape de paiement.
Options
  • PayPal
  • Visa
  • Mastercard
  • American Express
  • JCB
  • Discover
  • Diners Club
  • Google Pay
  • Apple Pay
Afficher tous les détails

Overview

The GEPRC SPEEDX2 1104 7500KV Motor is a compact motor for 1.6-2.2 inch lightweight drones, designed for 2-3S LiPo input (7.4-11.1V) and use with a 20A ESC.

Key Features

  • 7500KV ultra-high rotational speed; compatible with 3S batteries for fast response and control.
  • Integrated outrunner with CNC-machined high-strength carbon steel shell (resistant to deformation and impact damage).
  • N52H arc magnets with high-temperature demagnetization resistance.
  • NMB high-precision bearings for lower vibration at high RPM.
  • Multi-strand winding process for lower resistance and reduced heat.
  • 1.5mm standard shaft; compatible with most mainstream FPV propellers on the market.

For customer service, contact https://rcdrone.top/ or email support@rcdrone.top.

Specifications

Model GEPRC SPEEDX2 1104 7500KV Motor
Max Watt 155W
Peak current 13.2A (3S)
Interphase resistance 150 mOhm
Magnet N52H
Bearing type NMB
Configuration 9N12P
Dimension Dia 14.5 x 11.5mm
Shaft diameter 1.5mm
Shaft protruding length 4.95mm
Mounting holes 4-M2; mounting pattern Dia 9; center hole Dia 5
Lead 60mm / 28AWG
Recommended ESC 20A
Input volts 7.4-11.1V (2-3S LiPo)
Winding Multi-strand copper winding
Weight 5.2 +/- 0.2g (included wire)
Matching screws M2*4 Round Head Screw
Suitable for 1.6-2.2 inch lightweight drones
Mechanical drawing dimensions (reference) 17.2mm; 11.5mm; 7.8mm; 4.95mm; 2mm

Note: Dimensions and weight are for reference only. Actual product may vary.

Motor Test Data

Prop Throttle (%) Voltage (V) Current (A) Thrust (g) RPM Power (W) Efficiency (g/W)
GEMFAN 2219-3 30% 7.54 0.814 20.98 14854 6.14 3.42
GEMFAN 2219-3 50% 7.52 2.273 52.61 23961 17.09 3.08
GEMFAN 2219-3 100% 7.43 7.688 148.82 39878 57.12 2.61
GEMFAN 2219-3 30% 11.99 1.568 50.56 22458 18.80 2.69
GEMFAN 2219-3 50% 11.95 4.133 113.73 35099 49.39 2.30
GEMFAN 2219-3 100% 11.81 13.03 257.95 53902 153.88 1.68
HQprop-T2X2X3 30% 7.52 0.751 16.66 14773 5.65 2.95
HQprop-T2X2X3 50% 7.5 2.095 42.75 23462 15.71 2.72
HQprop-T2X2X3 100% 7.42 7.317 123.78 40904 54.29 2.28
HQprop-T2X2X3 30% 12 1.442 41.33 23696 17.30 2.39
HQprop-T2X2X3 50% 11.96 3.891 104.31 36449 46.54 2.24
HQprop-T2X2X3 100% 11.81 13.049 226.35 54321 154.11 1.47
HQprop-T2.2X1.6X3 30% 7.53 0.755 19.86 14540 5.69 3.49
HQprop-T2.2X1.6X3 50% 7.51 2.112 50.39 23741 15.86 3.18
HQprop-T2.2X1.6X3 100% 7.43 7.436 144.88 40582 55.25 2.62
HQprop-T2.2X1.6X3 30% 11.99 1.563 48.99 23905 18.74 2.61
HQprop-T2.2X1.6X3 50% 11.95 4.082 114.74 35907 48.78 2.35
HQprop-T2.2X1.6X3 100% 11.81 13.067 256.98 53351 154.32 1.67
GEMFAN 2020-D51MM-5 30% 7.53 0.932 21.99 15023 7.02 3.13
GEMFAN 2020-D51MM-5 50% 7.5 2.677 51.34 22788 20.08 2.56
GEMFAN 2020-D51MM-5 100% 7.4 9.209 134.73 35982 68.15 1.98

What's Included

  • 1 set: Motor x1; Screws x6 (M2*4 Round Head Screw)
  • 4 set: Motors x4; Screws x24

Applications

  • 1.6-2.2 inch lightweight drones
  • 2-3S LiPo (7.4-11.1V) power systems

Details

GEPRC SPEEDX2 1104 7500KV Motor, A powerful and responsive motor with N52H magnets and NMB bearings, suitable for 2-3S LiPo power.GEPRC SPEEDX2 1104 7500KV Motor, Integrated outrunner with N52H magnets and precision bearings ensures strong magnetic force, heat resistance, low vibration, and stable flight.

Integrated outrunner with N52H arc magnets and NMB high-precision bearings. CNC-machined shell resists deformation, ensuring strong magnetic force, high-temperature resistance, and lower vibration for stable flight.

GEPRC SPEEDX2 1104 7500KV Motor, Multi-strand winding lowers resistance and heat; 1.5mm shaft suits most FPV propellers.

Multi-strand winding reduces resistance and heat; 1.5mm shaft fits most FPV propellers.

GEPRC SPEEDX2 1104 7500KV motor: 155W, 13.2A peak, for 1.6–2.2" drones, 2–3S LiPo, weighs 5.2g.

GEPRC SPEEDX2 1104 7500KV motor specs: 155W, 13.2A peak, N52H magnets, NMB bearings, 9N12P, 14.5x11.5mm, 1.5mm shaft, 5.2g weight, suits 1.6-2.2 inch drones, 2-3S LiPo input.

GEPRC SPEEDX2 1104 7500KV Motor, Motor drawing: 17.2mm long, 14.5mm dia., M2 holes, 1.5mm shaft, 9mm & 5mm features.

Motor technical drawing: 17.2mm length, 14.5mm diameter, M2 holes, 1.5mm shafts, 9mm and 5mm features.

GEPRC SPEEDX2 1104 7500KV Motor, Compares GEMFAN and HQprop propeller performance (thrust, RPM, power, efficiency) at 7.4–12V for drone motor optimization across throttle levels.

Compares thrust, RPM, power, and efficiency across GEMFAN and HQprop propellers at 7.4–12V, showing performance metrics for drone motor optimization under varying throttle levels.

GEPRC SPEEDX2 1104 7500KV Motor, Model 1104 motor: 11.5mm H, 14.5mm W, 60mm shaft (1.5mm dia), 4.95mm top pin, 7500KV rated.

Motor dimensions: 11.5mm height, 14.5mm width, 60mm shaft length. Shaft diameter 1.5mm, top pin 4.95mm. Model 1104, 7500KV rated.

GEPRC SPEEDX2 1104 7500KV Motor, Motor weighs 5.2g on scale; display note for reference only.

Motor weighs 5.2g on scale; display note for reference only.

GEPRC SPEEDX2 1104 7500KV Motor, Magnetic materials with high-temperature resistance.GEPRC SPEEDX2 1104 7500KV Motor, NMB bearings offer high precision for reduced vibration at high speeds.GEPRC SPEEDX2 1104 7500KV Motor, Each set includes one 1104 7500kv motor and six screws; four sets contain four motors and 24 screws.

Product list: 1 set includes 1 motor and 6 screws; 4 sets include 4 motors and 24 screws. Motor labeled 1104 7500kv.
