Yahboom 1-Inch (25mm) Universal Caster Wheel, Nylon Bearing, M3 Mount, 10KG Load for Robot Chassis Car

Yahboom 1-Inch (25mm) Universal Caster Wheel, Nylon Bearing, M3 Mount, 10KG Load for Robot Chassis Car

Yahboom

$6.19 USD
$6.19 USD
İndirim Tükendi
Vergiler dahil. Kargo, ödeme sayfasında hesaplanır.
Option
  • PayPal
  • Visa
  • Mastercard
  • American Express
  • JCB
  • Discover
  • Diners Club
  • Google Pay
  • Apple Pay
Tüm ayrıntıları görüntüle

Overview

Yahboom 1-inch (25mm) universal caster wheel is designed for lightweight mobility needs on robot chassis and smart cars. It uses a high-strength nylon wheel with built-in precision ball bearings to deliver 360° smooth steering and quiet rolling, and it can be used with different chassis for compact, flexible movement.

Key Features

  • 360° universal rotation: Supports flexible movement for operation in small spaces.
  • Nylon wheel surface: Impact-resistant and wear-resistant; suitable for outdoor rough ground.
  • Precision ball bearings: Smooth steering and silent rolling.
  • M3 mounting support: Standard M3 screw-hole mounting for smart car and robot chassis integration.

Specifications

Wheel diameter 25 mm (1 inch)
Wheel width 13 mm
Tire material Nylon
Mounting hole diameter 4.7 mm
Installation height 33.5 mm
Base plate size 38*33 mm
Center distance of installation holes 29*23 mm
Weight 29.2 g
Single caster load 10 KG
Unit mm

What's Included

Shipping list varies by package:

  • 01: 1-inch Universal Wheel *1
  • 02 (for two-wheel drive L-type 520 motor chassis): 1-inch Universal Wheel *1; M3*25mm Double-pass copper pillar *4; M3*5mm Round head screw *8
    Notes: Copper pillars are suitable for combination with 65mm high-friction tires to ensure the levelness of the wheeled vehicle chassis.
  • 03 (for two-wheel drive 310 motor chassis): 1-inch Universal Wheel *1; M3*10mm Double-pass copper pillar *4; M3*5mm Round head screw *8
    Notes: Copper pillars are suitable for combination with 48mm rubber tires to ensure the levelness of the wheeled vehicle chassis.
  • 04 (for two-wheel drive TT motor chassis): 1-inch Universal Wheel *1; M3*16mm Double-pass copper pillar *4; M3*5mm Round head screw *8
    Notes: Copper pillars are suitable for combination with 65mm rubber tires to ensure the levelness of the wheeled vehicle chassis.

Applications

  • Robot chassis and smart cars (wheeled car chassis)
  • Small carts
  • Furniture and other lightweight rolling supports

For compatibility questions (for example, selecting the correct copper pillar length for a specific two-wheel drive chassis), contact support at https://rcdrone.top/ or email support@rcdrone.top.

Details

Yahboom 1-inch (25mm) universal caster wheel with nylon wheel and M3-mount base plate

Built for compact robot chassis and smart cars, the 1-inch caster adds smooth 360° steering with a durable nylon wheel.

Dimensions and specs for 25mm universal caster wheel: 33.5mm height, 38×33mm plate, 4.7mm holes, 10kg load

Detailed measurements help confirm clearance, mounting-hole spacing, and load rating before integrating into a chassis.

Shipping list header for Yahboom universal caster wheel package optionsClose-up of the 1-inch universal caster wheel showing nylon roller and four-hole mounting platePackage option 02: caster wheel with M3×25mm copper pillars and M3×5mm screws for L-type 520 motor chassis

Choose the L-type 520 option when you need the included standoffs and screws for a level install on that chassis style.

Yahboom 1-inch universal wheel for robot chassis and smart cars

The 310 motor chassis set includes shorter copper pillars to match common wheel heights and keep the chassis level.

Package option 04: caster wheel with M3×16mm copper pillars and M3×5mm screws for TT motor chassisCopper pillar length comparison for L-type 520, 310, and TT motor chassis (25mm, 10mm, 16mm)

Three copper-pillar lengths are provided across package options to match different two-wheel-drive chassis platforms.

Real product photos of the Yahboom 1-inch universal caster wheel from two angles on a white background
