GEPRC GEP-CL30 3-Inch FPV Frame Kit, 126mm, Prop Guards, 25.5x25.5 FC / 20x20 VTX

Overview

The GEPRC GEP-CL30 is a 3-inch FPV frame kit developed as an updated design based on the CL25, with mounting patterns intended for common AIO flight controllers and VTX systems (including VISTA and many analog VTX options). It uses a damping platform structure for improved vibration isolation and supports 3-inch propeller guards and a GP camera mount for compatible action cameras.

Key Features

• 3-inch FPV frame kit with propeller guard design
• Improved shock absorption (damping platform) for more stable video capture
• 25.5 mm x 25.5 mm FC mounting pattern and 20 mm x 20 mm VTX mounting pattern
• 9 mm x 9 mm motor mounting pattern; supports 1404–1408 motors
• Camera installation space: 14~19 mm
• Includes 3D-printed receiver-related mounts to simplify installation/binding

For build support or compatibility questions before purchase, contact support@rcdrone.top or visit https://rcdrone.top/.

Specifications

What’s Included

Carbon Plate

• 1 x Top Plate 2.0mm
• 1 x Arm Plate 3.0mm
• 1 x bottom Plate 2.0mm

Screws

• 2 x Knurled nut M2
• 4 x Aluminum Column M2x3.5×25
• 2 x M2x4mm cup head screws
• 28 x M2x6.5mm round head screws
• 10 x M2x8mm round head screws
• 7 x M2x9mm round head screws
• 4 x M2x10mm round head screws
• 1 x M2x12mm cup head screw
• 4 x M2x16mm cup head screws
• 1 x M2 Rivet nut
• 4 x M2 Lock nuts
• 8 x M2 Iron nuts
• 8 x M2 * 6.5mm damping rings
• 9 x damping platform rings

3D Printings

• 1 x 19x19mm Camera Mount
• 1 x VTX Antenna Mount
• 1 x TBS T-shaped Antenna Mount
• 1 x TBS NanoRX Mount
• 1 x Camera Protector

Injection Parts

• 6 x 3 in Propeller Guard
• 1 x GP Camera Mount

Other Parts

• 4 x EVA Damping Ring of Guards
• 2 x 3M Double Tapes
• 2 x Silicone Pads
• 2 x Landing Pads
• 1 x M15x200mm Battery Strap
• 1 x M15x150mm Battery Strap
• 1 x L-shaped (1.5mm)
• 1 x Antenna Tubes

Applications

• 3-inch FPV builds using AIO flight controllers
• Digital FPV builds using VISTA, or analog builds using many common VTX formats
• Compact builds requiring propeller guards and vibration-damped camera mounting
