Overview

DSpower DS-M005 and DS-M005B are PWM micro servo options with a JR 2.54 plug and 28T, Φ3.90 mm output shaft. Choose DS-M005 for a 3.7–4.2 V, 2.2 ± 0.3 g coreless option; choose DS-M005B for 5 V DC operation and 4.8 ± 0.2 g weight. DS-M005 is presented for compact RC-model and camera pan-tilt control work.

Features

Both versions use PWM communication, a 28T / Φ3.90 mm output shaft, and a JR 2.54 plug.
DS-M005 uses a coreless motor and is described with high-precision plastic gears and a long-life potentiometer.
DS-M005 provides a 500–2500 μs pulse-width range (180°) and 90° operating travel at 1000–2000 μs.
DS-M005B provides a 500–2500 μs pulse-width range and 90° operating travel.

Specifications

Parameter	DS-M005	DS-M005B
Brand	DSpower	DSpower
Product model	DS-M005	DS-M005B
Operating voltage	3.7–4.2 V	5 V DC
Static current	≤20 mA	≤40 mA
Stall current	≤350 mA	≤550 mA at 4.8 V; ≤600 mA at 6 V
Stall torque	≥0.35 kgf·cm	≥0.45 kgf·cm at 4.8 V; ≥0.5 kgf·cm at 6 V
Rotating direction	CCW (1000–2000 μs)	CCW (1000–2000 μs)
No-load speed	0.075 sec/60°	0.11 sec/60°
Pulse-width range	500–2500 μs (180°)	500–2500 μs
Operating travel angle	90° (1000–2000 μs)	90°
Return angle deviation	≤1°	≤1°
Weight	2.2 ± 0.3 g	4.8 ± 0.2 g
Communication interface	PWM	PWM
Wire length	150 mm	250 mm
Output shaft	28T / Φ3.90 mm	28T / Φ3.90 mm
Plug	JR 2.54	JR 2.54

Applications

DS-M005 is presented for drone camera adjustment, camera pan-tilt steering control, aircraft models, and remote-control helicopters. Its compact 2.2 ± 0.3 g weight and PWM control support space-conscious RC-model installations and small projects. Listed DS-M005 uses also include 1:35-scale, 1S-powered applications, indoor 3D planes, and micro park-flyer helicopters.
