DSpower DS-U006 Servo Motor, 6.0 V for Humanoid Robots, Robotic Arms and Exoskeletons

DSpower

$55.00 USD

Sale Ausverkauft

Inkl. Steuern. Versand wird beim Checkout berechnet

Version DS-U006

Anzahl

Vollständige Details anzeigen

Overview

The DSpower DS-U006 is a servo motor for robotic mechanisms including humanoid robots, robotic arms, exoskeletons, quadruped robots, AGV vehicles, and ARU robots. It operates from 4.8–6.0 V DC (6.0 V rated) and has a 0°/83° operating travel angle. Review its torque, current, pulse-width, backlash, and wiring values for system selection.

Specifications

Parameter	Value
Operating voltage	4.8–6.0 V DC
Rated voltage	6.0 V
Rated torque	1.75 kgf·cm
No-load current	≤180 mA
Stall current	≤1.5 A
No-load speed	<5 s/90°
Dynamic torque	7 kgf·cm
Pulse width range	300–2700 μs
Operating travel angle	0°/83°
Backlash	0.5°
Weight	93 g ± 1 g
Mechanical limit angle	90°
Wire length	210 mm

Applications

Listed application scenarios include humanoid robots, robotic arms, exoskeletons, quadruped robots, AGV vehicles, and ARU robots. The stated travel angle, pulse-width range, torque, and current values provide selection details for these servo-driven robotic mechanisms.
