RCDrone M4000 Industrial Drone Overview
The RCDrone M4000 Industrial Drone is a high-performance, multi-purpose industrial drone suitable for various operations such as firefighting, rescue, inspection, and surveying. This drone features excellent wind resistance, long flight duration, and a strong payload capacity. Key specifications include: expanded size of 1100×1100×600 mm, total weight of 12 kg, maximum payload of 10 kg, smart battery of 14S 54000mAh, and maximum flight speed of 15 m/s.
RCDrone M4000 Key Features
- High-Precision Camera: Equipped with a 2K HD 30x hybrid zoom gimbal camera, the RCDrone M4000 is suitable for firefighting, rescue, inspection, and nighttime operations. It supports high-precision and efficient surveying and inspection tasks.
- Long Flight Duration: The RCDrone M4000 can fly for up to 80 minutes without load and 30 minutes with a full load.
- Strong Wind Resistance: With a wind resistance level of 6, the RCDrone M4000 ensures stable flight even in harsh weather conditions.
- Foldable Design: The RCDrone M4000 is easy to carry and store, with expanded and folded sizes of 1100×1100×600 mm and 620×620×600 mm, respectively.
- Material: Made of carbon fiber, nylon fiber, and aluminum alloy, ensuring the RCDrone M4000 is lightweight and durable.
RCDrone M4000 Specifications
Parameter | Specification |
---|---|
Expanded Size | 1100×1100×600 mm |
Folded Size | 620×620×600 mm |
Total Weight | 12 kg |
Diagonal Wheelbase | 1400 mm |
Payload Capacity | 10 kg |
Takeoff Weight | 32 kg |
Smart Battery | 14S 54000mAh |
Maximum Flight Speed | 15 m/s |
Ascent Speed | 5 m/s |
Descent Speed | 5 m/s |
Wind Resistance Level | 6 |
Material | Carbon fiber/Nylon fiber/Aluminum alloy |
No Load Flight Time | 80 minutes |
Load Flight Time | 30 minutes |
Operating Temperature Range | -15°C to 40°C |
RCDrone M4000 Ground Station Specifications
Parameter | Specification |
---|---|
Display Device | 5.5 inch 1080P high-brightness LCD |
System Configuration | Android 9.0, 2G running memory, 16G storage space |
Dimensions (without antenna) | 189×138×41 mm |
Weight | 850 g |
Battery Capacity and Type | 10200 mAh 7.4V 2S Li-ion |
Fast Charging Protocol | PD 20W |
Charging Time | 5 hours (20W fast charge) |
Operating Time | 13 hours |
Functional Interfaces | Standard HDMI (professional version only), USB-A charging, Type-C data transmission, SIM card slot, SD card slot, USB-A tripod mount, 1/4 screw hole |
Waterproof Level | IP53 |
Operating Environment Temperature | -10°C to 50°C |
RCDrone M4000 Air Terminal Specifications
Parameter | Specification |
---|---|
Signal Output | 16 channels S.BUS, 5 channels PWM |
Functional Interfaces | S.BUS (GH1.25 3-Pin), UART (GH1.25 4-Pin), GH1.25 6-Pin video input/network data transmission, GPS antenna port (GH1.25 8-Pin), Type-C firmware upgrade interface |
Dimensions (without antenna) | 70×55×16 mm (including cooling module) |
Weight | 100 g (including cooling module) |
Antenna Gain | Omni-directional antenna: 5 dBi |
Operating Voltage | 14 – 58.8V |
Operating Environment Temperature | -10°C to 50°C |
RCDrone M4000 Communication Specifications
Parameter | Specification |
---|---|
Maximum Communication Distance | 15 KM (without interference, no obstacles) |
Plant Protection Operating Distance | 3.5 KM (3 meters flight altitude) |
Channels | Physical channels: 13, Communication channels: 16 |
Image Transmission Support Ground Station (Windows) | QgroundControl Mission Planner (H264 only) |
Conclusion
The RCDrone M4000 Industrial Drone is a reliable and versatile tool for various industrial applications. Its robust performance, multifunctional features, and durable design make the RCDrone M4000 suitable for precise surveying, nighttime inspections, and emergency rescues. The RCDrone M4000 meets the demands of complex tasks with its stable performance and exceptional capabilities.
What's Include:
Aerial firefighting Drone
1 x RCDrone M4000 Drone;
1 x Smart Battery;
1 x Remote Controller;
1 x ZR10 30x Zoom Gimbal Camera;
1 x Fire extinguisher Pod;
Delivery Drone
1 x RCDrone M4000 Drone;
1 x Smart Battery;
1 x Remote Controller;
1 x ZR10 30x Zoom Gimbal Camera;
1 x Cargo box Pod;
Patrol Drone
1 x RCDrone M4000 Drone;
1 x Smart Battery;
1 x Remote Controller;
1 x ZR10 30x Zoom Gimbal Camera;
1 x High decibel speaker;
1 x high brightness lighting search light;
Huge firefighting Drone
1 x RCDrone M4000 Drone;
1 x Smart Battery;
1 x Remote Controller;
1 x ZR10 30x Zoom Gimbal Camera;
1 x Huge Fire extinguisher Pod;
Note: If you want to customize the pod, please contact the RCDrone team
RCDrone M4000 Drone Details
Strong body structure
One-piece injection-molded body, internal multi-link skeleton structure, double the structural strength
Unfazed by Harsh Operating Environments
Dustproof and waterproof, unhindered by wind and rain; capable of operating within a temperature range of -10°C to 40°C, undeterred by extreme cold or heat, achieving all-weather operation.
New Smart Battery
Easy to plug and unplug, upgraded protection, ultra-long endurance, smart battery with variable frequency fast charging to meet power needs. Simplified power supply and balance port structure, making battery plugging and unplugging more convenient, further enhancing operational efficiency.
Battery Compartment
Manufactured using precision molding technology combined with high-strength steel for an integrated design. The press-type interface is not easily loosened, making it more secure and protecting the battery.
2K HD 30x Hybrid Zoom Gimbal Camera
The ZR10 supports 30x hybrid zoom, providing clear images even at distances over 100 meters. The algorithm is fast and accurate, with automatic focus on the viewpoint, making it easy to capture great shots.
RCDrone M4000 industrial drone features a 10kg payload, 80-minute flight time, and 15km range. Customized for fire fighting, delivery drones, and other heavy-duty applications.
If you want to customize the pod, please contact the RCDrone team
