SPECIFICATIONS

Use: Vehicles & Remote Control Toys

Tool Supplies: Assembled class

Technical parameters: Value 4

Remote Control Peripherals/Devices: Discharger

Recommend Age: 14+y

Quantity: 1 pcs

Origin: Mainland China

Model Number: TA3000

Material: Composite Material

Four-wheel Drive Attributes: Battery

For Vehicle Type: Airplanes

Brand Name: aerops

Safety Instructions:

• Before using this product, please read the following safety instructions. Please
follow each instruction to ensure your safety. Improper operation may result in
serious injury to the user and/or property damage.
• Do not use the charger unattended, if there’s any abnormality, please
disconnect the power supply immediately;
• Keep the charger away from a humid environment and heat sources during
use; please pay attention to proper ventilation, heat dissipation, and keep away
from flammable materials at all times.
• Please check the equipment for damage before use. Do not use the device if it
is damaged;
• Do not place metal debris in or on any parts of the charger, or it may cause
damage to the device or injury to the user.
• This product is not a toy; do not allow children to operate the charger.
• After use, disconnect the power cord;
• Do not try to charge non rechargeable dry batteries;
• Please pay attention to the setting of the battery type when using; wrong
settings may lead to serious injury to the user and/or property damage;
• Do not disassemble the product. There are no user serviceable parts inside.

2. Product overview No. Function description No. Charging port A Balance port A Display Screen Storage/ChannelReturn button Fast charging/Up button Stop/Confirm/Setting button Standard charing/Down button USB port Balance port 10 .

Technical Specifications: Channel Count: Dual Battery Type: Lithium-Polymer (LiPo) and Lithium-Hybrid (LiHv) Charging Power: - AC Input (11V): Maximum 120W - DC Input (220V): Maximum 3000W Balancing Cells: 6-14S Operating Temperature Range: 0-65°C Output Interface: USB, SOP, and B-Modes Fast Charge Voltage: - LiPo: 4.2V - LiHv: 4.35V Storage Temperature Range: -20°C to 60°C

The touchscreen display shows charger settings, charging status, and other relevant information. Meanwhile, the intuitive buttons enable easy equipment operation.

Connect the charger to the power source, and after approximately 2 seconds, the screen will display the product's logo interface, followed by a split-screen display.

ttu CHAe 00.00;00 Ittu CHB 0.Ov O.Ov MO.OA 0.OmAh 0J0.OA 0Ov ACZZOv 0,Ovlov 0.oviow 25"C/77FF 25C/778F 000.00,00

The TA3000 charger features a user-friendly interface with two channels: Channel A and Channel B. The main parameters displayed include: Channel A: brand information (NEW TATTU); voltage O.00V - 14.00V; current state (Idle or Input); input voltage AC 0.00V - 20.00V; output power 0.00W - 30.00W; and current temperature 25°C/77°F. Additionally, the charger offers a split-screen display that shows the current temperature in real-time.

This charger detects when Channel A is connected to a smart battery, displaying the corresponding channel logo in yellow on the split-screen interface. To access information about the connected battery, use the 'Up/Down' button as shown.

The charger detects that Channel A is linked to the smart battery and displays its corresponding logo in yellow on the split-screen interface, indicating a successful connection.

The TATTU TA3000 charger is specifically designed to charge and discharge TATTU smart batteries only. When viewing the split-screen display, pressing and holding the 'up' button will initiate fast charging mode.

Should you encounter any unusual circumstances during charging, please stop the charging process immediately or unplug the charger. Additionally, ensure that the battery is securely connected to the charger before attempting to remove it. Failure to do so may cause damage to the battery or charger.
