Overview

The Kpower DHV026 is a coreless servo motor for R/C models, drones and equipment positioning tasks. Its 4.8–8.4 V operating range, metal gears and compact 35.8 × 15 × 29 mm body help buyers assess power and mounting requirements. PWM, TTL and RS-485 are listed control protocols. The servo combines potentiometer position sensing, two ball bearings and a plastic-and-aluminum-alloy case, with a specified 120° travel range that is customizable.

Features

High-voltage coreless motor designed for efficient operation and low energy consumption.
High-precision machined metal gears.
Plastic-and-aluminum-alloy case with CNC-machined aluminum-alloy housing construction.
Potentiometer position sensor and two ball bearings.
PWM, TTL and RS-485 control protocols.
25T output spline with a 5.79 mm diameter.

Specifications

Parameter	DHV026 specification
Model	Kpower DHV026
Product designation	25G Semi-Aluminum Coreless High-Voltage Standard Servo
Stall torque	5.5 kg (unit as supplied)
Rated torque	1.5 kg (unit as supplied)
No-load speed	0.11 s
Weight	28 g
Dimensions	35.8 × 15 × 29 mm
Travel angle range	120°; customizable
Operating voltage	4.8–8.4 V
Horn gear spline	25T, Ø5.79 mm
Gear material	Metal; high-precision machined gears
Motor	Coreless motor
Protocols	PWM, TTL, RS-485
No-load current	2000 mA
Position sensor	Potentiometer
Case material	Plastic + aluminum alloy; CNC-machined aluminum-alloy housing construction
Ball bearings	2BB (two ball bearings)
Working frequency	50–333 Hz
Operating temperature	−10 to 50 °C
IP rating	IP42

Applications

R/C model and drone mechanism positioning: Use the servo to actuate linkages requiring controlled angular travel, with metal gears and a 120° travel specification.
Smart-home appliance mechanisms: Incorporate angular actuation where the compact body and 4.8–8.4 V supply range fit the mechanism's mounting and power requirements.
Medical-equipment mechanisms: Provide angular positioning within equipment designs that require a compact servo with potentiometer position sensing.
