RadioLink RC6GS V3 SPECIFICATIONS
Use: Vehicles & Remote Control Toys
Remote Control Peripherals/Devices: Remote Controller
Recommend Age: 12+y,14+y
RC Parts & Accs: Radio Systems
Quantity: 1 pcs
Plastic Type: ABS
Origin: Mainland China
Model Number: RC6GS V3
Material: Plastic
For Vehicle Type: Cars
Brand Name: RadioLink
Note: free delivery in some countries.
The radio equipment meets the following essential requirements: (a) health and safety testing, including electromagnetic compatibility and radiated power limits, as per the relevant regulations.
RadioLink RC6GS V3 - 7-Channel Dual Mix Programmable Telemetry System for Vehicle Batteries, Gyro Integrated, and USB Upgrade. Features 600M Ground Distance, Anti-Pug Protection, and 100% FHSS ICH Random Pseudo Channel Kade.
RadioLink RC6GS V3 features improved specifications compared to its predecessor, RC6GS V2. Key upgrades include an ARM M4 processor, 10 models supported in storage (upgradable to support 30 models), and a firmware upgrade required for full functionality. The timer function is also available, with the ability to set a switch to turn on or off features like PMIXO2 Low Voltage and RSSI Alarm independently for each model. Additionally, the TTBS Crossfire function is compatible with TBS products.
Introducing the RadioLink RC6GS V3, a 7-channel programmable radio system with dual mix control, timer, and head tracker function. This system is compatible with TBSCrosstire models, gyro integrated, and HNV sensors supported. It also features customizable FSS setting and a Crube Conbol system for enhanced performance.
The GFSK LCD screen features a high-resolution display of 128x64 pixels, with a backlight channel resolution of 4096. The radio also employs Spread Spectrum technology, specifically Frequency Hopping Spread Spectrum (FHSS), which uses 67 channels in a pseudo-random frequency sequence. Additionally, the device is equipped with a low-voltage alarm feature.
The new RC6GS-V3 features a fixed hole on its mobile phone stand, which includes six channels: Channel 1 (Rudder), Channel 2 (Throttle), Channel B (Setup for Shift Gear), Channel Z (100 percent default setting), and Setup for Front Locker.
Features include First-Person View (FPV) head tracking, TBS Crossfire function, Long Distance Outdoor Operation System (LDOOS), and RadioLink proprietary features.
The waterproof receiver (RZFG) will be packaged with the RC6GS V3. This device features a waterproof coating similar to that used on smartphones, utilizing nanotechnology for added protection.
RadioLink RC6GS V3: A 7-channel multi-function upgrade with 600m/400m ground distance, gyro integrated, and dual mix programmable features from Radiolink, a China-made product.
RadioLink RC6GS V3 - R7FG R6FG R6F: A programmable, dual-mix receiver with 6 channels and 7 channels, featuring a maximum ground distance of 600M and 400M in gyro mode, as well as integrated telemetry for monitoring vehicle battery levels.
The equipment connection diagram for RadioLink RC6GS V3 is a nice TTT-150A kind of power, with WTE LAN fold R7FG. Ha Daejeon Bivo Led; 5U/504A35 L, with V channels in a rett.
The RadioLink R6FG is a 2.4 GHz, 6-channel receiver that features integrated gyro capabilities. It is compatible with various RadioLink transmitters, including the RC6GS, RC4GS, T8FB, and T8S models.
Enter XP (Throttle EXP) mode, IDLE UP (Idle-Up) protocol, to set the throttle high-side priority and improve engine starting performance. Additionally, adjust the maximum steering angle and configure STEXP REV (Servo Reverse) for optimal control.
The RC6GS has excellent resistance to interference, ensuring reliable performance in both simultaneous and non-simultaneous frequency operations up to a distance of 600 meters.
To use all features, including two-way transmission, users need to upgrade their RC6GS V3 controller with the latest firmware version (V6.0.0). This ensures compatibility with the iEZ 4 module, which allows for easy setup and control of mix functions.
Q1: What battery is suitable to work with RC4GS/RC6GS? What's the voltage range?
A: The JST connector of RC4GS/RC6GS can be easily adapted for various battery, including LiPo battery of 2S to 4S and 6pcs of AA batteries. The voltage range is 4.8V to 15V.
Q2: Does RC4GS/RC6GS have telemetry function?
A: Yes. RC4GS with firmware of V6.0.1 and above/RC6GS with firmware of V6.0.0 and above is capable of returning signal strength, RSSI, RX voltage. If work with RadioLink receiver R7FG/R8F, vehicle voltage can also be returned. However, telemetry of motor speed and temperature is NOT available yet.
Q3: Can RC4GS/RC6GS control TRAXXAS or twin-engine RC cars?
A: Sure. RC4GS/RC6GS is a perfect remote control to all types of on-road electric powered or gasoline cars and twin-engine cars, tracked vehicles, crawlers, drift cars, tractor trucks, nitro cars, mini cars, sailboats, fishing boats.
Q4: How to setup dual ESC with RC4GS/RC6GS?
A: Select whichever two preferred channels and refer the PROGRAMMABLE MIX CONTROL setup part in the user manual of RC4GS/RC6GS or click below link for the detailed steps to setup mix control http://radiolink.com.cn/doce/programmable-dual-mix-control.html
Q5: How many models RC4GS/RC6GS can store?
A: RC4GS/RC6GS can store 10 models data at most.
Q6: What are the compatible receivers to RC4GS/RC6GS?
A: The standard packed receiver of RC4GS is R6FG while that of RC6GS is R7FG. Both of these two pistol grip radios are compatible with R6FG, R7FG, R8F, R6F, R4FGM and R4FGM is specially developed for mini cars.
Specifications: Frequency Range 4.8GHz, Current Consumption 1mA, Dimension 14*21*13mm, Weight 6.5g, Operating Distance up to 1900m, RZFG FHSS Technology with TBFB and TBS modes available. Additional features include gyro integration and dual mix programmability across 6 or 7 channels.
Note
* All RadioLink transmitters are not open sourced and can only bind to receivers developed by RadioLink. Vice versa.
Q7: How to do the binding between RC4GS/RC6GS and receivers?
A: All the binding of RadioLink transmitters and receivers is the same. Power on the products, long press the binding button on the receiver and release, the led indicator always on means the binding is done. Click the tutorial video to learn more https://youtu.be/Kxjzt4vzqU4
