CUAV PW-LINK Wifi Telemetry Module SPECIFICATIONS
Wheelbase: Upper Shell
Use: Vehicles & Remote Control Toys
Upgrade Parts/Accessories: Hydraulic Transmission Box
Tool Supplies: Cutting
Technical parameters: KV1100
Size: 28*17*1.2 mm
Remote Control Peripherals/Devices: Receivers
Recommend Age: 18+
RC Parts & Accs: Transmitters
Quantity: 1 pcs
Origin: Mainland China
Model Number: PW-LINK
Material: Metal
Four-wheel Drive Attributes: Shell/Chassis/Wing/Head
For Vehicle Type: Airplanes
Certification: CE,FCC
CUAV PW-LINK Wifi Telemetry Module Wifi Data Transmission for PIX FPV Telemetry PIXHACK PIXHAWK Flight Controller
PW-Link product description
Network processor - high performance,ESP8266;
• all kinds of mobile devices can be connected quickly through WiFi module;
It should be used in all kinds of ground station software supporting UDP communication;
PW-Link product features
wifi password: cuavwlink Specification Range 200m Wireless standards IEEE I1g.IEEE 802.1b Wireless speed Ilg: Maximum 54Mbps.
wireless standards IEEE 802.11gQIEEE 1lg07] The highest54Mbps[ transmission speed 1Mbps attended mode UDPQ14552 channel range 1 - 13 frequency range 2412 2472 transmitting power 18dbm antenna type UFL type Wireless safe WPAVWPA2 security communication protocols Transparent transmission traffic rate 57600 working voltage; 5v 0,25v working current 1OOMA working temperature -20 50o Operation humidity 109 90%RHD] nonc Storage Temperature 40 809 Storage Humid
PW-Link Product summary
The pw-link data transmission module is divided into built-in antenna and external antenna version. The built-in antenna version is only suitable for pix flight control near distance and regulate the use of the calibration parameters, and the external antenna version after a number of practical test and reasonable transmission distance is 450 meters. The use of computer mission planner ground station for a long time the connection test, average stability data the transmission signal is maintained at more than 90%. Because of its small size, long transmission distance, stable data, convenient connection characteristics, very suitable for small UAV data receiving several hundred metres.
PW-Link The whole communication mode is as follows:
the average stability of data transmission signal is maintained above 90% Due to its features of small volume; long transmission distance_ stable data and convenient connection . it is very suitable for the use of various calibration and adjustment parameters in short distance, as well as the data transmission and reception mode of small unmanned aerial vehicles .
mobile phones, computers and other devices can wirelessly connect to unmanned aerial vehicles . ESP8266 high-performance network communication processor Simple and Fast UDP broadcast communication mode with Iow over- head .
