GAIA 160MP Hexacopter - 20KG Payload Heavy Lift Industrial Drone

GAIA 160MP Heavy Lift Drone - 20KG Payload, 48KG Takeoff Weight, 30-Inch Propellers

The GAIA 160MP is a versatile, heavy-lift hexacopter designed for professional applications requiring substantial payload capacity and long flight endurance. With a wheelbase of 1620mm, it supports a 20KG payload and a takeoff weight exceeding 48KG, making it ideal for tasks like aerial photography, emergency rescue, and cargo delivery. Its carbon fiber frame ensures durability and lightweight performance, while the 30-inch high-efficiency propellers and powerful motors allow for stable, long-duration flights. The quick-locking pluggable arm design enables easy transport and rapid setup, perfect for field operations.

Highlighted Features:

Heavy Load Capacity & Stability
The GAIA 160MP can carry payloads up to 20kg, making it suitable for tasks requiring substantial load capacity, such as industrial inspections, cargo transport, and professional cinematography.

Carbon Fiber Frame with Weather Resistance
Constructed with carbon fiber, the frame offers high strength and lightweight properties, ensuring durability in tough environments. Its closed fuselage design protects from rain and dust, enhancing the drone's weather resistance and ease of maintenance.

High-Efficiency Power System
The GAIA 160MP is equipped with 30-inch propellers and powerful motors, enabling long flight times and stable performance even under heavy loads. This makes it highly efficient for extended missions.

Quick Setup & Easy Transportation
The drone features a quick-lock pluggable arm design that allows for fast setup and easy transport, reducing downtime and improving operational efficiency in critical missions like emergency rescue.

Versatile Payload Options
Compatible with various equipment, the GAIA 160MP can support professional gimbals such as the DJI Ronin 2, making it ideal for aerial cinematography with high-end cameras like RED Dragon or Canon C300.

Optional Equipment and Configurations:

• Flight Controllers: DJI N3 or DJI A3
• Batteries: Foxtech Diamond 6S Semi-solid State Lipo or TATTU 22.8V 6S 10C High Voltage Lipo
• Remote Controllers: DJI Lightbridge 2 or Futaba 14SG
• Gimbal: Ronin-MX
• Motor and ESC Combo: Foxtech 8120 100KV with FOC ESC HV

The GAIA 160MP Heavy Lift Drone provides a robust solution for industries needing high payload capacity, stability, and reliable performance in demanding environments.

Package Listings:

Drome Frame:

-1 x GAIA 160MP hexacopter frame

-1 x Dual Landing Gear

A3 RTF Combo:

-1 x GAIA 160MP hexacopter frame
-6 x T-MOTOR P80 III KV100
-6 x T-MOTOR FLAME 80A HV V2.0
-3 x 3010 Carbon Fiber Propeller
-1 x DJI A3 flight controller
-1 x DJI Lightbridge 2
-1 x Dual Landing Gear
-1 x EFT V3 High Current Power Distribution Board

-1 x Assembly and Fly Test Package

-1 x Plug/Cable/Wires/Shrink Tubing etc

N3 RTF Combo:

-1 x GAIA 160MP hexacopter frame
-6 x T-MOTOR P80 III KV100
-6 x T-MOTOR FLAME 80A HV V2.0
-3 x 3010 Carbon Fiber Propeller
-1 x DJI N3 flight controller
-1 x DJI Lightbridge 2
-1 x Dual Landing Gear
-1 x EFT V3 High Current Power Distribution Board

-1 x Assembly and Fly Test Package
-1 x Plug/Cable/Wires/Shrink Tubing etc

Pixhawk RTF Combo:

-1 x GAIA 160MP hexacopter frame
-6 x T-MOTOR P80 III KV100
-6 x T-MOTOR FLAME 80A HV V2.0
-3 x 3010 Carbon Fiber Propeller
-1 x Pixhawk Cube Orange Standard Set with Here 3 GNSS
-1 x Foxtech DA16S+ 16-Channel Radio Controller
-1 x Dual Landing Gear
-1 x EFT V3 High Current Power Distribution Board

-1 x Assembly and Fly Test Package
-1 x Plug/Cable/Wires/Shrink Tubing etc

Pixhawk Fire Fighting RTF Combo:

-1 x GAIA 160MP hexacopter frame
-6 x T-MOTOR P80 III KV100
-6 x T-MOTOR FLAME 80A HV V2.0
-3 x 3010 Carbon Fiber Propeller
-1 x Pixhawk Cube Orange Standard Set with Here 3 GNSS
-1 x Foxtech DA16S+ 16-Channel Radio Controller
-1 x Dual Landing Gear
-1 x EFT V3 High Current Power Distribution Board
-1 x Foxtech RDD-6(fire extinguisher balls not included)
-1 x 6-Channel Radio Controller
-1 x Assembly and Fly Test Package
-1 x Plug/Cable/Wires/Shrink Tubing etc

Options:

- Flight Controller: DJI N3/DJI A3
- 4x Battery
- Remote Controller: DJI Lightbridge 2/Futaba 14SG Radio Controller
- Gimbal: Ronin-MX

GAIA 160 MP Hexacopter, heavy-lift drone with a wheelbase of 1620mm and take-off weight of 248kg.

The GAIA 160MP Hexacopter is a new integrated flight platform released by Foxtech. With its lightweight design and heavy-load power system, it greatly enhances the performance and reliability of GAIA 160. The spacious area between the center board and the ground allows for various equipment to be loaded, making it applicable to all kinds of industries such as aerial photography, emergency rescue, reconnaissance missions, remote sensing surveys, and mapping.

Battery groove size: 213 x 66 mm. Long and narrow design maximizes internal space, rational structure for high space utilization.

The GAIA 160MP Hexacopter features a high-quality camera for capturing stunning aerial footage. With its advanced flight controller, this drone provides precise control and professional-grade stabilization.

Max lift of one rotor: 13 kg. GAIA Hexacopter Drone features a powerful 040 04x4 P8O motor, high-efficiency 80A ESC and durable 3010 carbon fiber propeller.

Both covers and arms can be quickly locked with the locking hooks, making it convenient for storage and transportation setup.

EBCOT extends the shooting angle, optimizes appearance and accommodates a large payload; compatible with multiple gimbals
