SKYZONE SKY04X V2 FPV Goggles - OLED 5.8GHz 48CH Receiver 1280X960 Display FPV Goggles Support DVR With Head Tracker Fan For RC Racing Drone

The SKY04X V2 is First skyzone goggle with focos adjustment,the 1280*960 high resolution screen have vivid color and high contrast ration,pilot can see more details in the racing.
With Steadyview receiver, the receiver mergｅ two signal to one,avoid image tearing and rolling, make image more stable and clear in challenging condition.
The new designed optics have focos adjustment feature and 46 degree Field of view, gives pilots more immersive FPV experience.
The new OS with 10 languages to set select, pilot have no trouble with the menu system, with shuttle wheel and new user interface, pilot can set all the setting just by rolling the wheel without take off the goggles.

*SteadyView Receiver
SteadyView receiver mergｅ two signal to one, make image more stable and clear in challenging condition.
With module bay, goggles have more capability to upgrade.

*Focos Adjustment
The new Optics have large Field of View (46 degree). and the Optics have Focos adjustment feature (-6~+6), no need diopter any more.

*OELD Screen
The 1280*960 screen have high resolution and vivid color, high contrast ration, pilots can see more details.

*Advanced Screen Settings
The aspect ration can is switchable, and 4 Preset screen setting and 3 customized setting for indoor, outdoor flight or different weather.

*Shuttle Wheel Control
No more confusing multi function button or 5 way Joy stick, with smooth and nature shuttle control, easy to navigate.

*New User Interface with 10 languages.
New UI with shuttle wheel, easy to navigate, 10 languages to choose for local user.

Parameter
Brand: SKYZONE
Model: SKY04X V2
Item: 5.8GHz 48CH Steadyview Receiver 1280X960 FPV Goggles
Screen: OLED
Resolution: 1280X960
FOV (Diagonal): 46°
AspectRatio: 4:3/16:9
Focos: -6~+6 adjustable
Interpupillary distance(IPD): 58-71mm
Receiver: 5.8Ghz 48CH Steadyview Receiver
Language: 10 Language
Power Supply: DC6.5-25.2V/USB5V
PowerConsumption: 720mAat12V
DVR: H264,60fps, MOV6Mbps, SD Card support up to 128Gb
Head Tracker: 3-axis Accelerometer, 3-axisgyroscope
Dimentions: 185*75*67mm
Weight: 267g

Packing List
Goggles*1
Receiver Module*1
Faceplate*2
Sponge with velcr0*1
Zipper case*1
Power cable*1
Headtracker cable*1
5.8GHz 2dD antennas*2
Video/Audio Cable*1
USB-C Cable*1
Uer Manual*1
Packing*1

BAND/CHANNEL table:
CH1: (A)5865M, (B)5733M, (E)5705M, (F)5740M, (R)5658M, (L)5362M
CH2: (A)5845M, (B)5752M, (E)5685M, (F)5760M, (R)5695M, (L)5399M
CH3: (A)5825M, (B)5771M, (E)5665M, (F)5780M, (R)5732M, (L)5436M
CH4: (A)5805M, (B)5790M, (E)5645M, (F)5800M, (R)5769M, (L)5473M
CH5: (A)5785M, (B)5809M, (E)5885M, (F)5820M, (R)5806M, (L)5510M
CH6: (A)5765M, (B)5828M, (E)5905M, (F)5840M, (R)5843M, (L)5547M
CH7: (A)5745M, (B)5847M, (E)5925M, (F)5860M, (R)5880M, (L)5584M
CH8: (A)5725M, (B)5866M, (E)5945M, (F)5880M, (R)5917M, (L)5621M
Sensitivity: -98dBm±1dBm
Antenna Port: 2xSMA-K,50ohm

Adjust shutter wheel control, steady view receiver languages, new UI advanced screen settings.

Skyzone Sky04X V2 FPV Goggles feature an OLED display and a steady view receiver, with a module bay that allows for easy upgrades and additional capabilities.

The Skyzone Sky04X features an OLED display with a large field of view (46 degrees), along with a focus adjustment feature that allows for adjustments between +6 diopters and -6 diopters.

The SKY04X V2 FPV Goggles feature an impressive 1280x960 OLED screen, offering high resolution and vivid colors for exceptional detail visibility. In contrast, lower-resolution displays can lack details and color vibrancy, while also introducing latency issues. With the SKY04X's high resolution, high contrast ratio, and low latency, pilots can enjoy a more immersive and detailed flying experience.

SkyZone Sky04X OLED FPV goggles feature advanced screen settings with switchable aspect ratios. You can choose from four preset settings, including options for indoor, outdoor flight, and different weather conditions, as well as three customizable settings.

Experience seamless navigation with the SKYZONE Sky04X's innovative OLED Shuttle Wheel Control. Say goodbye to complex multiple-function buttons or 5-way joysticks - instead, enjoy smooth and intuitive control with our intuitive shuttle wheel system.

The SKYZONE Sky04X features an OLED display with a new user interface that supports 10 different languages. This intuitive design incorporates a shuttle wheel, making it easy to navigate through settings and menus, while also providing language options for users from around the world.
