T-MOTOR U13 II KV65 KV130 Motor SPECIFICATIONS
Wheelbase: Screws
Use: Vehicles & Remote Control Toys
Upgrade Parts/Accessories: ESC
Tool Supplies: Battery
Technical parameters: Value 2
Size: heavy lift drone motors
Remote Control Peripherals/Devices: Remote Controller
Recommend Age: 14+y
RC Parts & Accs: Propellers
Origin: Mainland China
Model Number: U13 II
Material: Metal
Four-wheel Drive Attributes: Motors
For Vehicle Type: Airplanes
Brand Name: T-MOTOR
U13-A leap of thrust improvement NEWLY RELEASED #Redesigned iron core *Sine wave features #FOC ESC drive #Heat Resisting Wires U13ukv1xe L 8 MADEinCHINa 1 Tmotor designimamUfaC
![T-MOTOR, Thrust Volt Propeller Power Ratio U13 1300g 17360g 48](https://rcdrone.top/cdn/shop/files/Hcfc7456a21ab4be282e4aa95856c2179h.webp?v=1715461320)
Features: Thrust [value], Voltage [48V], Propeller Power Ratio, U13 II motor with 1300g thrust, 17360g propeller power, 29x9.5 tri-blade design, and maximum weight [24KG].
![T-MOTOR U13 II KV65 KV130 Motor SPECIFICATION](https://rcdrone.top/cdn/shop/files/He7cec7e2525746ea9c839e36715a60442.webp?v=1715461330)
![T-MOTOR, max thrust of new U13 reaches 24.3kg from 17.4kg which greatly elevates](https://rcdrone.top/cdn/shop/files/Ha232e237d34d403594b1c9cc2459aadfT.webp?v=1715461334)
The newly designed U13 motor boasts an impressive maximum thrust of 24.3 kg, a significant increase from its predecessor's 17.4 kg. This upgrade enables aircraft payloads to be greatly elevated.
![T-MOTOR, max thrust of new U13 reaches 24.3kg from 17.4kg which greatly elevates](https://rcdrone.top/cdn/shop/files/H33d9b95854134ea0a59db27817760c9c3.webp?v=1715461344)
The newly designed U13 motor features a significant increase in maximum thrust, reaching 24.3 kg, up from 17.4 kg, allowing for increased payload capacity. Additionally, the new iron core design enables even greater thrust capabilities, with values ranging from 25 kg at full speed down to 14.65 kg.
![T-MOTOR, the remarkable cooling performance guarantees the reliability during even running in 508C environment . SSS](https://rcdrone.top/cdn/shop/files/He4efc674ccb849f8a0136f87077ca7b7I.webp?v=1715461347)
The T-MOTOR U13 II KV65/KV130 motor features an efficient cooling system that ensures reliable performance, even in extreme temperatures up to 508°C. The SSS Efficient Cooling System is a high-temperature air-cooling system designed to provide optimal heat dissipation.
![T-MOTOR, Motor Protection For safe flight New Dust Prevention Network Dual bearing protection for longer service life and stability of](https://rcdrone.top/cdn/shop/files/H3a6c7ac67d144e749297bd7595d2c9aez.webp?v=1715461350)
Motor Protection: Ensure Safe Flight with Enhanced Durability. This feature provides dual-bearing protection, shielding both bearings and motors from environmental factors such as sand, dust, and foreign matter, as well as magnetic particles, to prolong service life and maintain stability.
![T-MOTOR, Iron Core Special anti-rust treatment: passing 48h salt spray test MIIIIO .](https://rcdrone.top/cdn/shop/files/Hb011600af46c4add828bd7df42acf275y.webp?v=1715461358)
![T-MOTOR, Service Life 1500 flights are out of question 40mins/flight . Redesign of](https://rcdrone.top/cdn/shop/files/H2d8b4d813e1446da9657cefc421b2175a.webp?v=1715461361)
Service life: This motor can withstand an astonishing 1500 flights, with each flight lasting approximately 40 minutes. Additionally, the custom bearings contribute significantly to prolonging the bearing's lifespan, reaching an impressive 1000 hours of trouble-free operation.
![T-MOTOR, high grade magnets improve torque for high efficiency in high temperature . 150(C) 180](https://rcdrone.top/cdn/shop/files/H2fd04a6e879547658ea8678c23fe33ec7.webp?v=1715461365)
The T-MOTOR U13 II KV65/KV130 motor features upgraded N42 UH arc magnets, replacing traditional N42 SH square magnets. This high-grade magnet design enhances the motor's torque and efficiency, particularly in high-temperature applications.
![T-MOTOR U13 II KV65 KV130 Motor SPECIFICATION](https://rcdrone.top/cdn/shop/files/Hff71d76b85b14c1daba428d9189ebc5eq.webp?v=1715461372)
![T-MOTOR, Specifications Test Item KV130 Weight (Incl. Cable) Motor Dimensions](https://rcdrone.top/cdn/shop/files/H8abbda917f9c416ea555e3731b25a465g.webp?v=1715461375)
Specifications for the KV130 motor include: Weight (including cable): [insert weight] Motor dimensions: 100mm x 60mm Internal resistance: 8mΩ Lead enameled wire configuration: 36N42P Shaft diameter: 1Smm Rated voltage (Lipo): 10-14.5V Idle current (1.8V): 1.5A Peak current (1.8V, 80s): 11.8A Maximum power: 6,720W Weight (without cable): 975g
![T-MOTOR U13 II KV65 KV130 Motor SPECIFICATION](https://rcdrone.top/cdn/shop/files/H4bd9e198b4474651a756eac96157551ee.webp?v=1715461384)
![T-MOTOR U13 II KV65 KV130 Motor SPECIFICATION](https://rcdrone.top/cdn/shop/files/Hf729152505044c9086001029e82f415cs.webp?v=1715461398)
![T-MOTOR, if something is missing, please contact online customer service or leave message to onlinesales@](https://rcdrone.top/cdn/shop/files/H46b09c219a6b41fd843831cb76195934h.webp?v=1715461401)
For any inquiries or concerns regarding this product, please feel free to reach out to our online customer service or email us at onlinesales@tmotorcom.com.
